Platform · Workflows

Decide what a verification means, per use case.

Q: Can workflows be versioned?

Every workflow change is recorded in the audit log. Archiving a workflow keeps the sessions that used it intact.

Q: Can I list workflows from the API?

Yes, GET /v1/workflows returns the app's workflows so your backend can choose one.

A workflow is the configuration a session runs: which steps the person completes, which background checks run at submit, the thresholds, the accepted documents and countries, and whether a failed check declines or goes to review.

Try it in your browser Start free

kycverify · productworkflows

configurable steps and checks: 9
fixed hosted-flow positions, consent to submit: 7
default workflow per app: 1

No-code builder

What it checks

Workflows, check by check.

Each rule below is what the engine actually runs.

Steps
Email OTP, document, Aadhaar, PAN and liveness are steps the person completes, always in the order consent, email, document, Aadhaar, PAN, liveness, review.
Background checks
Face match, AML, age and duplicate run at submit, from what the steps collected.
The decision rule
Any failed check declines (or goes to review with auto-decline off); any check in review or error goes to review; otherwise approved.
Redirect
Send the person back to your app when they finish, with an optional redirect URL.

Try it

Build a workflow and read its consequences.

Toggle steps and checks. The journey redraws in the hosted flow's fixed order, the config is generated as the console saves it, and the same validation rules tell you what would be refused.

The rules are ported line for line from the Rust engine, and the page names the file.
Everything runs locally in this tab. No request is made while you type.
Reset puts the example back; nothing is saved.

Workflow builder, in miniature

Runs in your browser

Start from

liveness.challenges

1 to 4.

The hosted flow, in its fixed order

Consent
Document
Liveness
Submit

Then, at submit

Face match
AML
Duplicate
IP (always)

Valid configuration

Save it in the console, or pass its workflow_id when you create a session.

workflow config

{
  "steps": {
    "document": {
      "enabled": true,
      "allowed_types": [
        "passport",
        "id_card",
        "driving_licence",
        "residence_permit",
        "aadhaar",
        "pan",
        "voter_id"
      ],
      "allowed_countries": [],
      "reject_expired": true,
      "max_attempts": 3
    },
    "liveness": {
      "enabled": true,
      "challenges": 3,
      "max_attempts": 3
    },
    "face_match": {
      "enabled": true,
      "threshold": 0.363,
      "review_threshold": 0.3
    },
    "aadhaar": {
      "enabled": false,
      "methods": [
        "secure_qr",
        "offline_xml"
      ],
      "max_xml_age_days": 3,
      "require_signature": true
    },
    "pan": {
      "enabled": false,
      "require_card_image": false
    },
    "email": {
      "enabled": false
    },
    "aml": {
      "enabled": true,
      "lists": [
        "ofac_sdn",
        "un_consolidated"
      ],
      "match_threshold": 0.9,
      "review_threshold": 0.82
    },
    "age": {
      "enabled": false,
      "min_age": 18
    },
    "duplicate": {
      "enabled": true,
      "face_threshold": 0.55,
      "scope": "app"
    }
  },
  "decision": {
    "auto_decline": true
  },
  "redirect_url": null
}

Logic ported from backend/crates/kyc-api/src/workflow_config.rs. Nothing you type leaves this page.

How it works

What happens, in order.

1
Build
Toggle steps, set thresholds with live previews, pick countries and document types in the console.
2
Preview
The journey preview shows exactly which screens the person will see.
3
Use
Pass workflow_id when you create a session, or let the app's default workflow apply.

Configuration

The workflow keys and their defaults.

Workflow · json

{
  "steps": {
    "document":   { "enabled": true },
    "liveness":   { "enabled": true, "challenges": 3 },
    "face_match": { "enabled": true, "threshold": 0.363 },
    "aml":        { "enabled": true },
    "duplicate":  { "enabled": true }
  },
  "decision": { "auto_decline": true },
  "redirect_url": null
}

Key	Default	Meaning
decision.auto_decline	true	A failed check declines; off sends it to review instead.
redirect_url	null	Where the hosted flow sends the person at the end.

Reference

Every step, its default and its knobs.

Every step, its default and its knobs.
Key	Default	Settings
email	off	-
document	on	allowed_types, allowed_countries, reject_expired, max_attempts
aadhaar	off	methods, max_xml_age_days, require_signature
pan	off	require_card_image
liveness	on	challenges (1-4), max_attempts
face_match	on	threshold, review_threshold
aml	on	lists, match_threshold, review_threshold
age	off	min_age
duplicate	on	face_threshold, scope (app or org)
decision	auto_decline on	auto_decline

What the console refuses

The same validation runs on every save, from the console or the database.

Workflows codes
Code	Outcome	When
A workflow needs at least one user-facing step	refused	Email, document, Aadhaar, PAN or liveness must be on.
Face match needs the liveness (selfie) step	refused	There is no selfie to compare without liveness.
Age check needs a document or Aadhaar step	refused	There is no date of birth to read otherwise.
Liveness challenges must be 1-4	refused	There are four challenge types and each is issued at most once.
review threshold must be <= the match threshold	refused	Applies to face match and AML alike.

API

Choose a workflow per session.

List the app's workflows, then pass a workflow_id when you create a session. Without one, the app's default workflow applies.

Checks reference Developer overview

Choose a workflow per session.

curl https://kycverify.me/api/v1/workflows -H "x-api-key: $KYC_API_KEY"

curl -X POST https://kycverify.me/api/v1/sessions \
  -H "x-api-key: $KYC_API_KEY" \
  -H "content-type: application/json" \
  -d '{ "workflow_id": "wf_…", "vendor_data": "user-42", "expires_in_hours": 48 }'

201 Created

{
  "session_id": "ses_…",
  "status": "not_started",
  "url": "https://kycverify.me/verify/q3Xf…",
  "workflow_id": "wf_…",
  "vendor_data": "user-42",
  "expires_at": "2026-10-05T09:12:44Z"
}

Limits

What it does not do.

Stated up front, so you can decide what to pair it with.

Step order in the hosted flow is fixed. Workflows choose which steps appear, not their order.
